| General |
Aspect Ratio |
16:9 (Native) 4:3 |
| Brightness (ANSI Lumens) |
850 ANSI Lumens |
| Contrast Ratio |
1300:1 |
| Display Type |
0.7" Polysilicon TFT Active Matrix LCD x 3 |
| Resolution (Native / Max) |
HD (1280 x 720)
HD (1920 x 1080) |
| Video Compatibility |
PAL, PAL-M, PAL-N, PAL 60, SECAM, NTSC, NTSC 4.43, HDTV (480i, 480p, 625i, 625p, 720p, 1080i) |
| Projection Lens |
F = 1.9 ~ 2.2
f = 22.0 ~ 26.2mm |
| Number of Colors |
16.77 Million Colors |
| Size |
Dimensions (WxHxD) |
11.0in. x 3.3in. x 10.6in.
(27.94cm x 8.38cm x 26.92cm) |
| Weight |
6.4 lbs. (2.9 kg) |
| Connectivity |
Inputs |
1 x DVI-I
1 x Component
1 x RGB D-Sub 15pin
1 x RCA Video
1 x S-Video
1 x Stereo Mini Jack
1 x Scart |
| Operation |
Power Supply |
100 ~ 240 V / 50 ~ 60 Hz |
| Power Consumption |
180W (Normal)
1W (Standby) |
| Operating Temperature |
32°F ~ 104°F (0°C ~ 40°C) |
| Operating Humidity |
20 ~ 80% (Non-Condensing) |
| Projection Lens |
Lamp Type |
130W UHM |
| Projection Distance |
3.9ft. ~ 30.2ft. (1.19m ~ 9.2m) |
| Projection Mode |
Front, Rear, Ceiling, Desktop |
| Projection Screen Size (Diagonal) |
40in. ~ 200in. (101.6cm ~ 508cm) |
| Optical Zoom |
1.2:1 |
| Horizonal Keystone Correction |
+/- 30 Degrees |
| Vertical Keystone Correction |
+/- 30 Degrees |
| Brightness Uniformity |
90% |
| Other |
Menu Languages |
English, French, German, Spanish, Italian, Chinese, Japanese |
